The unique Above-the-Floor Rough (AFR) feature for bathtubs leaves a few inches of clearance between the product’s underside and the flooring so pipes can be routed without breaking ground or relocating the drain. Perfect for installation on a concrete slab in renovation or new construction.
Key Benefits
- Rectangular shape bathtub in alcove installation
- Available in Above-the-Floor Rough (AFR) or not
- Minimalist look with discreet armrests and textured floor
- Deck for faucet installation
- When equipped with a system, the unit comes with an access panel
- Compatible with U tile shower wall panels
Attribute Set
- Above-the-Floor Rough : Yes
- Installation Type : Alcove
- Material : Acrylic
- Residential Warranty : 25 Years
- Commercial Warranty : 25 Years
Characteristics
- Made in North America
- Elegant Design
- Integrated Tiling Flange and Skirt
- Dimension: 59 3/4" x 32" x 19 1/2"
- Another SKU: 105512-L-000-001-001
| Product Information | |
|---|---|
| Deck Width: | 4 1/8" |
| Bathing Well Width: | 25 7/8" |
| Width: | 32" |
| Maximum Door Width: | 58 1/4" |
| Bathing Well Length: | 53 1/4" |
| Length: | 59 3/4" |
| Maximum Water Capacity: | 38.00 G |
| Deep Sump Height: | 16 1/4" |
| Packaging Dimension: | 24.00 ft³ |
| Minimum Water Capacity: | 35.00 G |
| Height: | 19 1/2" |
| Approximative Weight: | 78.00 lb |
